Pearl Mini User Guide Add a text overlay
For best results always upload images that are already the correct size needed in your layout.
Background images should match the frame size of your channel (frame size is set in the Encoding
configuration page).
There are two ways to upload images and video files. You can upload images and videosfrom the Media page
using the Admin panel or drag and drop your image onto the Add new item area using the custom layout editor,
see
Add an image to a layout .
Important considerations
l Media file names should not include special characters, slashes, or spaces. The underscore character "_"
is allowed.
l Uploading an image of the same name overwrites the existing image.
l Any image without the proper file extension appears in the layout editor but doesn't display in the actual
video output. For instance, a .PNG image with the file extension .bmp or an invalid file extension such as
.png2 are examples of improper file extensions.
Upload or remove an image using the Admin panel's Media page
1. Log in to the Admin panel as admin, see Connect to the Admin panel .
2. From the Configuration menu, click Media. The Media page opens.
3. To upload a file, click Choose File and browse to select the file to upload, then click Upload.
4. To remove a file, click Remove beside the file name and click OK when prompted.
If you delete an image that is used as part of the layout for any channel, select a different image or
no image by using the drop-down list in the Picture settings box within that channel's layout before
deleting the file using the steps below.
Add a text overlay
Text overlays are useful to add information like a title, location, or the date and time in to layouts in your channel.
You can add text to any layout using the custom layout editor. The following tables lists shortcut codes that you
can enter and the resulting content that appears on screen.
Table 43 Overlay text shortcut codes
Item Shortcut code Example
date format: yyyy-mm-
dd
%F 2019-01-26
date format: mm/dd/yy %D 01/26/19
year %G 2019
