Pearl Mini User Guide Select the video output source using the device screen
l Recording - The recording status of the channel
l - Currently recording
l
- Recording error
l Stopped - Not currently recording
l Streaming - The streaming status of the channel
l - There are active publishers. The numbers show how many publishers are active.
l
- Publishing errors, and the number of publishing errors.
l Actual FPS - The current rate of frames per second
Audio Inputs
A list of the active audio inputs on the Pearl device.
l Input name - the name of the audio input
l Audio meter -
l
- the audio is
live and the input is being monitored
Select the video output source using the device screen
It's easy to change the video source that appears at the video output port using the front screen or touch screen.
For video sources that have audio, you can enable and disable the audio as well. Audio is enabled by default.
To configure the video output port parameters, use the Admin panel. See Video output ports .
Select the video output source using touch screen on Pearl-2 or Pearl Mini
1. From the touch screen, tap the gear icon to open the System settings screen. If the control icons aren't
showing, tap anywhere on the touch screen.
2. Tap the arrow icon in the lower-right corner of the screen to go to the second Settings page.
