Pearl Mini User Guide
Set up an SRT stream using rendezvous mode
5. (Optional) Uncheck Single touch control if you don't want this stream to be started and stopped using
Single Touch streaming and recording control
. This is enabled by default.
6. Enter the URL of the ingestion point provided by the CDN or media server.
l
For RTMP push, enter rtmp followed by the rest of the URL, for example:
rtmp://<server-ip-
address>:<port>/etc...
l
For RTMPS, enter rtmps followed by the rest of the URL, for example:
rtmps://<server-ip-
address>:<port>/etc...
7. Enter the Stream name (which also is called a stream key by some CDNs)
8. (Optional) Enter a User name and Password.
The CDN provider assigns a user name and password to authenticate the publisher. Contact
the CDN provider for your log in credentials. Some CDNs, like YouTube and Facebook Live,
do not require you to enter your log in credentials here.
9. (Optional) Rename the stream. Click the current name and enter a different name, then press Enter.
Refresh your browser if the new stream name doesn't immediately display.
10. Click Apply.
11. To start streaming, click Start or click Start all to simultaneously start this stream and any other streams
you have configured for this channel.
12. Click Delete this stream at any time to delete the stream.
See
Start and stop streaming to a CDN
for instructions to control streaming from the touch screen or see
Control
streaming and recording using Epiphan Live
for instructions to use Epiphan Live.
Set up an SRT stream using rendezvous mode
Secure Reliable Transport (SRT) is an open-source streaming protocol that offers quality, low latency streaming
to CDNs and other SRT enabled decoders across unreliable Internet connections via UDP.
The easiest way to establish a link between the SRT source and destination devices is to use rendezvous mode.
In rendezvous mode, both the SRT source and destination device are ready to establish the SRT connection as
soon as an SRT stream starts.
258
