Pearl Mini User Guide Run diagnostic tests using the device screen
2. Do one of the following:
a. If Ping is selected, enter the destination server IP address or domain name in the empty field.
b. If Trace route is selected, enter the destination server IP address or domain name to routetrace in
the empty field.
c. If Bandwidth test is selected, the measured upload and download bandwidth displays after you
click Start.
d. If Domain name resolution is selected, enter the IP address or server name to resolve in the empty
field.
e. If Probe is selected, choose the transport protocol from the drop-down menu and then enter the
destination server IP address or server name along with the port in the empty field. For example,
enter:
10.100.10.1:1234 or domain.example.com:1234
3. Tap Start.
420
