Pearl Mini User Guide View system information using the touch screen
Item Description
Streaming has an error.
Streaming timer
The streaming timer shows the length of time that streaming
has been in progress.
Recording status
Recording indicator appears in the top-right corner:
(no dot) Recording is disabled.
Gray means recording is stopped.
Flashing red means recording is in progress.
Recording has an error.
Recording timer
The recording timer shows the length of time that recording has
been in progress.
Audio VU meter
Audio VU meter for the channel uses quasi-peak ballistics with
samples averaged every 10 ms. The maximum average audio
level in each 100 ms period is displayed using colored bars.
l RED = 0 to -9 dBFS
l Yellow = -9 to -18 dBFS
l Green = -18 dBFS and lower
To monitor a different channel, tap the right or left arrows on the channel view to see the next (or previous)
channel. If the touch screen controls aren't showing, tap anywhere on the touch screen to make them reappear.
To get back to the grid view, tap the grid icon .
View system information using the touch screen
Find the serial number, check the installed firmware version of your Pearl Mini and more on the System Status
screen using the touch screen.
The System Status screen displays basic system information that's useful when first setting up your Pearl Mini.
