Pearl Mini User Guide
Multicast streaming using RTP/UDP
udp://@ip:port
For example: udp://@226.10.24.32:7000
To view the stream when SAP announce has been set and the stream is advertised from a media player, set-top
box or Smart TV, refer to
Viewing with Session Announcement Protocol (SAP)
.
If you're streaming to 10/100 Mbps set-top boxes over Gigabit Ethernet and you notice frames are dropping, you
can limit the bandwidth of the stream, see
Set up traffic shaping
.
Multicast streaming using RTP/UDP
You configure an RTP/UDP (push) stream on Pearl Mini using the Admin panel.
If you're streaming to 10/100 Mbps set-top boxes over Gigabit Ethernet and you notice frames are dropping, you
can limit the bandwidth of the stream, see
Set up traffic shaping
.
Configure a channel to stream using RTP/UDP push
1. Login to the Admin panel as admin, see
Connect to the Admin panel
.
2. From the Channel(s) menu, select the channel and click Streaming. The Streaming configuration page
opens.
3. Click New stream and select RTP/UDP push.
4. Enter the following:
l
Destination multicast IP address.
l
Audio port number through which the audio will stream.
l
Video port number through which the video will stream.
Audio and video use nearby port numbers (<port number>and <port number+2>). The minimum
distance between audio and video ports must be 2.
5. Click Apply. An SDP file is generated.
6. From the channel's Status page, click the SDP file to download it. Provide the SDP file name and location
if prompted.
7. Share the file with your viewers and when you're ready to start streaming, select Start.
Set up traffic shaping
If you're multicasting to set-top boxes that have 10/100 Mbps interfaces on the same Gigabit Ethernet and you
notice frames are dropping, you can limit the bandwidth of the stream using traffic shaping to adapt for the lower
bandwidth set-top boxes. Only multicast streams support traffic shaping: MPEG-TS USP, MPEG-TS RTP/UDP,
and RTP/UDP.
