Pearl Mini User Guide Channel layout examples
Layout example
Epiphan
products
Description
All
One video source with a logo (.png
with transparency) in the bottom left
corner.
To get this look: Upload an image
with transparency. Using the custom
layout editor, add one video source
to the layout, select keep aspect
ratio and stretch to fill the entire
layout area. Then, add the image to
the layout and drag it where you
want it to appear on screen.
All
One source with a text overlay in the
bottom right corner.
To get this look: Using the custom
layout editor, add one video source
to the layout, select keep aspect
ratio and stretch to fill the entire
layout area. Then, add a text overlay
to the layout and drag it where you
want it to appear on screen.
All
One video source (a slideshow
presentation in this case), with a
green background matte.
To get this look: Using the custom
layout editor, select a background
color. Add a video source to the
layout and size appropriately,
leaving the background matte
visible.
167
