Pearl Mini User Guide Configure LDAP user authentication
2. From the Configuration menu, select Security. The Security configuration page opens.
3. In the LDAP authentication section, check Enable LDAP authentication. Uncheck the check box to
disable LDAP authentication.
4. In the Server address[:port] field, enter the server IP address and (optional) port for your LDAP server.
For example, 192.168.1.101:389.
5. In the Connection encryption drop-down, choose the type of encryption used by your LDAP server (if any
is used).
Connection encryp-
tion
Description/Default port used
No Encryption No encryption is used to connect to the LDAP server. The default port is 389.
SSL SSL encryption is used to connect to the LDAP server. The default port is 636.
TLS/STARTTLS
The connection is initially unencrypted then upgraded to TLS encryption is used.
The default port is 389.
6. In the Bind DN and Bind password fields, specify the fully qualified DN and password for LDAP bind.
These fields are only needed if your LDAP server does not support anonymous binding.
7. In the Base DN field, specify the baseObject to search for entries. The system will search this object and
the whole subtree starting at the base DN.
8. (Optional) By default the Authentication attribute is uid, which is suitable for a unix environment. You can
specify a different value in the Authentication attribute field, if needed. For Active Directory
environments, specify
userPrincipalName. The value of this attribute must be unique in the Base DN.
9. In the Administrators (group DN) field, specify the distinguished name of the group users must be part of
to be logged in as the administrator. Users must have the member or uniquemember attribute for the
specified group to be granted Administrator access.
If left blank, LDAP is not supported for Administrators (but can still be used for Operators and Viewers).
10. In the Operators (group DN) field, specify the distinguished name of the group users must be part of to be
logged in as the operator. Users must have the member or uniquemember attribute for the specified group
to be granted Operator access.
If left blank, LDAP is not supported for Operators (but can still be used for Administrators and Viewers).
11. In the Viewers (group DN) field, specify the distinguished name of the group users must be part of to be
logged in as a viewer. Users must have the member or uniquemember attribute for the specified group to
be granted Viewer access.
If left blank, LDAP is not supported for Viewers (but can still be used for Administrators and Operators).
12. Click Apply.
When a user of the LDAP server next visits the admin or viewer page for the system, the system prompts for use
the username and password. For ActiveDirectory servers, the user needs to enter his fully qualified username
(i.e. username@domainname) in addition to his LDAP password.
