Pearl Mini User Guide About the Admin panel
Label Name Description
The Pearl Nano has a single channel.
2
Recorders menu(Pearl
Mini and Pearl-2 only)
Recorders you add to your Pearl device are listed. Select a recorder to
open the status page and list of related recordings for that recorder.
You can start and stop recording, as well as configure the recorder
settings from this page.
3 Inputs menu
The available video and audio input ports on your Pearl device are
listed. Select a port to open the configuration and status page for that
port.
4 Output ports menu
The output ports available on your Pearl device are listed. Select a
port to open the configuration and status page for that port.
5 Events menu
Access the Content Management System (CMS) events list containing
up to three months of scheduled CMS events, in progress events, and
completed ah hoc and scheduled events.
6 Configuration menu A list of all the available configuration options.
7
Internal storage and
system information menu
System details are displayed in this area, such as the total amount of
internal storage, how much space is currently used, and how much
free space is available.
8 Main panel
The main panel is where the selected menu information displays.
What's displayed depends on which menu item you select.
9
Link to Epiphan Live
(Pearl-2 and Pearl Mini
only)
Click to open Epiphan Live in a new tab.
10 Log out
Click to log out of the Pearl admin panel. Click icon again to display the
log in window. The role of the currently logged in user displays beside
the icon.
You can access the Admin panel using these methods:
l Any web browser, see Connect to the Admin panel .
l Using a connected USB mouse, keyboard, and monitor, see Enable local console access to the Admin
panel .
l Remotely using Epiphan Edge, see Remote login to the Admin panel and Epiphan Live .
BETA DRAFT - 57
