Pearl Mini User Guide Configure AFU to CIFS server parameters
Name Description
Checksum
Select to enable checksum checking during file transfer. This increases the time taken to
transfer, but also increases reliability of the transfer.
Prerequisites
l Channels and recorders are already added for AFU, see Set channels and recorders to include in AFU .
l AFU is enabled and the parameters configured, see Enable AFU, schedule, and set options .
Configure AFU upload to an RSync server using the Admin panel
1. From the Automatic File Upload configuration page, select RSync Client as the protocol transfer type.
2. Specify the target Server address. If your system is configured with DHCP or has a valid DNS
configuration (see Configure DHCP ), you can use the server’s fully qualified domain name instead of the
IP address.
3. Specify the Server module. This is the name of the shared folder on the server. If needed, request this
value from your network administrator.
4. Specify a username for the RSync Server in the Login field. The user must have write permissions for the
module.
5. Specify the password for the user in the Password field; the value is masked by dots.
6. (Optional) Select the Checksum check box to add a checksum validation to the transfer between the
system and the recipient server.
7. Click Apply.
Configure AFU to CIFS server parameters
You can automatically upload recordings to a CIFS server (also known as SMB or samba) when you select CIFS
as the AFU protocol transfer type using the Admin panel. SMB2 and SMB3 are supported.
