Pearl Mini User Guide Switching and mixing using the touch screen
If an error occurs when you start streaming, a yellow circle with an exclamation mark appears
in the left top corner of the touch screen. Check your networking and streaming settings.
Pearl devices also feature One Touch, which lets you control recording and streaming of multiple channels and
recorders at the same time with the touch of a button. See
Single Touch streaming and recording control for
more information.
Switching and mixing using the touch screen
Switching live video inputs, or video mixing, is simple and intuitive using the Pearl device's touch screen.
After you select the channel you want to live switch, tap the Live Switcher icon along the bottom of the touch
screen to open the live switcher. All custom layouts that are configured for the channel display in the carousel.
Simply tap a layout to load it in to the standby panel and you're ready to start live switching.
Performing live switching using one interface, like the touch screen, does not dynamically
update the visuals in the other interfaces (e.g. the Admin panel and Epiphan Live). The other
interfaces must be manually refreshed to accurately reflect the current live switching layout
information.
If the live switching controls don't appear on the touch screen, they may have been disabled. see Disable or
enable recording, streaming, and switching from the touch screen .
Switch custom layouts for a channel using the touch screen
1. Tap the Live Switcher icon to open the live switcher view for the channel. If the control icons aren't
showing, tap anywhere on the touch screen.
BETA DRAFT - 38
