Pearl Mini User Guide Pearl Mini tech specs
Encoded channels
Up to three 1080p channels at 30 fps with one full
HD video source per channel (recommended)
Streaming protocols
MPEG-TS, and FLV
RTSP over TCP/UDP
SRT (push) over UDP
HLS (push) over HTTP/HTTPS
Multi-Publish to Streaming Server / CDN (SRT,
RTSP, RTMP, RTMPS)
HLS (pull) - Native Apple HTTP/HTTPS stream for
iPad, iPhone and iPod Touch
Multicast streams
RTP/UDP, MPEG-TS & RTP, and MPEG-TS over
UDP
SAP
Stream encryption and
authentication
SRT: 128 bits, 192 bits, or 256 bits AES
encryption (negotiated) and configurable
passphrase
HLS (push): MD5, SHA-256, and SHA-512
RTMPS: encryption plus CA certificate negotiation
Resolution ranges
Recorded: 480p to 1920×1200p
Confidence monitoring: 480p to 1920×1200p
Streamed: 480p to 1920×1200p
Frame rate Up to 60 fps
Formats
H.264/AVC (ITU H.264, ISO/IEC 14496-10) 4:2:0,
8 bit color
l Encoding profile: High, Main, Baseline
l Profile levels: 3.0, 3.1,3.2,4.0,4.1
Motion JPEG
Network traffic shaping
(multicast streams)
4 Mbps to 95 Mbps (configurable)
Audio output
Analog audio output (1) 3.5 mm stereo headphone jack - front panel
Digital audio outputs
RTSP and SRT audio over Ethernet
HLS audio over HTTP/HTTPS
HDMI audio (embedded)
BETA DRAFT - 25
