Pearl Mini User Guide Pearl Mini power adapter specifications
3
You can connect a USB, RTSP, SRT, or NDI|HX source to Pearl Mini; however, using multiple digital sources
can affect performance depending on your setup. If you experience performance issues, check CPU usage and
take remedial actions like: remove some configured layouts, reduce the channel's frame rate, or remove a video
input.
4 Digital audio is de-embedded from the digital source.
5 SD-SDI audio is not supported.
6 SD card is reserved for system use and cannot be used to transfer files to other devices like a laptop. Use a
USB memory device to manually transfer files instead.
7
Remote login requires an Epiphan Edge Pro account.
Pearl Mini power adapter specifications
An AC to DC power adapter model FSP060-DHAN3 comes with your Pearl Mini.
Table 7 AC to DC power adapter FSP060-DHAN3 specifications
Parameter Value
Input voltage 90-240 VAC
Input AC frequency 47 to 63 Hz
Output voltage 12 VDC
Output current 5 A
Output power 60 W
Active efficiency (average) 88 %
Efficiency (10 % load) 95 %
No-load consumption 0.075 W
Manufacturer FSP Group Inc./No. 22, Jianguo E. Road, Taoyuan city, Taiwan
Optimum System Load
While Pearl Mini is powerful, there is a limit to the number of concurrent tasks the onboard CPU can perform
efficiently.
The number of concurrent tasks depends on many factors, such as:
l the number of video sources
l what frame rate and bitrate is used for a channel
l if the video output ports are used
l if a live monitor is connected to the HDMI output port (about the equivalent of an encoded 1920×1080@30
fps channel)
BETA DRAFT - 29
