Pearl Mini User Guide Set up a stream to the CDN using an XML profile
4. Click the stream name to see the stream settings.
5. (Optional) To rename the stream, click the current name and type a different name, then press Enter.
Refresh your browser if the new stream name doesn't immediately display.
6. (Optional) Uncheck Single touch control if you don't want this stream to be started and stopped using
Single Touch streaming and recording control (checked by default).
7. Enter the following parameters:
l The URL of the ingestion point provided by the CDN or media server.
l Select the Transport type as either UDP or TCP. Consult your CDN provider to find out which
transport protocols the CDN supports.
l The CDN User name and Password (if required).
The CDN provider assigns a user name and password to authenticate the publisher. Contact
the CDN provider for your log in credentials.
8. Click Apply.
9. To start streaming, click Start or click Start all to simultaneously start this stream and any other streams
you have configured for this channel.
10. Click Delete this stream at any time to delete the stream.
See Start and stop streaming to a CDN for instructions to control streaming from the touch screen or see Control
streaming and recording using Epiphan Live for instructions to use Epiphan Live.
Set up a stream to the CDN using an XML profile
Some CDNs provide an XML file for easy configuration setup. Pearl Mini supports using XML profiles to set a
stream.
Set up a stream using an XML profile from the CDN
1. Log in to the Admin panel as admin, see Connect to the Admin panel .
2. From the Channels menu, select the channel and click Streaming. The Streaming configuration page
opens.
