Pearl Mini User Guide Restrict viewers by IP address
Restrict viewer access to watch streams for all channels by their IP address
1. Login to the Admin panel as admin, see Connect to the Admin panel .
2. From the Configuration menu, select Security. The Security configuration page opens.
3. Enter the allowed IP addresses or address ranges in the Allow IP’s field and enter denied IP addresses or
address ranges in the Deny IP's field. Separate addresses with a comma. To specify a range, use a
hyphen (-). Optional spaces improve readability.
4. Click Apply.
Restrict viewer access to watch streams on a channel by their IP address
1. Login to the Admin panel as admin, see Connect to the Admin panel .
2. From the Channels menu, select a channel and click Streaming. The channel's streaming configuration
page opens.
3. From the Stream access control drop-down, select Use these Settings to enable local password and
Allow/Deny IP lists are enabled.
4. (Optional) Enter a password for the viewer in the Viewer Password field.
5. Enter the allowed IP addresses or address ranges in the Allow IP’s field and enter denied IP addresses or
address ranges in the Deny IP's field. Separate addresses with a comma. To specify a range, use a
hyphen (-). Optional spaces improve readability.
6. Click Apply.
IP restriction examples
The following table lists some sample allow lists.
Table 32 Example allow lists
Example Description
Allow list with distinct IP
addresses
The simplest allow/deny list is to use the list of known IP addresses to craft a
list of allowed IP addresses. All other addresses are denied access to the
broadcast.
For example if your system is accessible on your local area network (LAN) and
you want to make sure only the CEO’s specific desktop, laptop and tablet
computers (with IP Addresses 192.168.1.50, 192.168.1.51, and 192.165.1.75,
respectively) can connect to the broadcast, construct the following allow list:
Allow: 192.168.1.50, 192.168.1.51, 192.168.1.75
Allow list with a range of IP
addresses
Sometimes you’ll want a range of computer IP addresses to connect to your
system. This may happen when you have one range of IP addresses assigned
to desktop computers (i.e. in the range 192.168.1.1 to 192.168.1.100) and
another range assigned to boardroom computers (i.e. the range 192.168.1.200
