Pearl Mini User Guide Crop a video source
If you use a non-monospaced font, the size of the text overlay changes as the letters, numbers, and
the length of words change. Use a monospaced font to maintain a consistent size for the text overlay
(assuming the total number of characters in the text string doesn't change).
The RS-232 SET command syntax in this case is VAR.SET. <name> = <value> , for example:
VAR.SET.gpsvar1=N103 68201 W765 29712
where <name> is gpsvar1 and <value> is N103 68201 W765 29712.
There are no limits for the frequency of system variable commands using RS-232. However, only one command
can be issued at a time.
HTTP system variable commands are issued at a frequency of 5 per second. You can include up to six variables
in a single HTTP SET command. After issuing a SET command, all channels using the specified variables are
updated.
System variables are considered volatile. They are deleted when a Pearl system reboots.
To learn more about global variable command syntax and important considerations when using them, see the
Pearl System API Guide for details.
For more information about sizing and positioning elements in the custom layout editor area, see About the
custom layout editor .
Crop a video source
You can crop a video source to change the size and shape of your video as it appears on screen using the
custom layout editor. Cropping a source gives you a lot of advantages and can help to conserve the overall
amount of processing CPU usage for Pearl Mini.
214
