Pearl Mini User Guide Delete, move, or duplicate a layout
If you delete all the layouts in a channel until there is only one layout left and that layout has only one video
source assigned, then the channel name changes back to the name of the video source.
To avoid channel name changes, we recommend that you rename the channel to a custom name. Changing the
channel name to a custom name ensures that no automatic channel renaming happens, see
Rename a layout .
Reorder layouts using the Admin panel's custom layout editor
1. Login to the Admin panel as admin, see Connect to the Admin panel .
2. From the Channels menu, select a channel and click Layouts. The custom layout editor opens.
3. In the layouts list, click and drag the icon with the three horizontal bars at the left side of the row to
rearrange the order of your layouts.
Delete a layout using the Admin panel's custom layout editor
You can delete any layout except the currently active layout.
1. Login to the Admin panel as admin, see Connect to the Admin panel .
2. From the Channels menu, select a channel and click Layouts. The custom layout editor opens.
3. Click the X at the right side of the row for the layout you want to delete. The system prompts you to make
sure you want to delete the layout.
4. Click OK.
When using the switcher on Epiphan Live, refresh your browser if you still see a layout that was
deleted. The deleted layout should disappear.
Duplicate a layout using the Admin panel's custom layout editor
If you're planning to use live switching, we strongly recommend you rename the channel rather than using the
default channel name, see
Rename a channel .
1. Login to the Admin panel as admin, see Connect to the Admin panel .
2. From the Channels menu, select a channel and click Layouts. The custom layout editor opens.
