MSD-54 SERIES User’s Guide
54
16:9 video signal Right&left sides
are cut
Right&left sides
are cut
Right&left
sides are cut
Right&left
sides are cut
5:3 video signal Right&left sides
are cut
Right&left sides
are cut
Rigtht&left sides
are cut
Top&bottom
sides are cut
5:4 video signal Top&bottom
sides are cut
Top&bottom
sides are cut
Top&bottom
sides are cut
Top&bottom
sides are cut
4:3 video signal Right&left
sides are cut
Top&bottom
sides are cut
Top&bottom
sides are cut
Top&bottom
sides are cut
Input signal
4:3 5:4 5:3 16:9 16:10
Aspect ratio of destination display device*
[Selecting “SIDE CUT/TOP BOTTOM CUT” for aspect ratio restoration processing]
* Each aspect ratio is found on the basis of the aspect ratio selected for the display device.
[Figure 8.16] Restore aspect ratio -2(1/2)
