User’s Manual of SGSD-1022 / SGSD-1022P
SGSW-2840 / SGSW-2840P
groupname -Name of an SNMP group to which the user is assigned. (Range: 1-32 characters)
remote - Specifies an SNMP engine on a remote device.
ip-address -The Internet address of the remote device.
v1 | v2c | v3 - Use SNMP version 1, 2c or 3.
encrypted -Accepts the password as encrypted input.
auth - Uses SNMPv3 with authentication.
md5 | sha - Uses MD5 or SHA authentication.
auth-password -Authentication password. Enter as plain text if the encrypted option is not used. Otherwise, enter an
encrypted password. (A minimum of eight characters is required.)
priv des56 - Uses SNMPv3 with privacy with DES56 encryption.
priv-password - Privacy password. Enter as plain text if the encrypted option is not used. Otherwise, enter an encrypted
password.
Default Setting
None
Command Mode
Global Configuration
Command Usage
The SNMP engine ID is used to compute the authentication/privacy digests from the password. You should therefore
configure the engine ID with the snmp-server engine-id command before using this configuration command.
Before you configure a remote user, use the snmp-server engine-id command (page 4-75) to specify the engine ID for the
remote device where the user resides. Then use the snmp-server user command to specify the user and the IP address
for the remote device where the user resides. The remote agent’s SNMP engine ID is used to compute
authentication/privacy digests from the user’s password. If the remote engine ID is not first configured, the snmp-server
user command specifying a remote user will fail.
SNMP passwords are localized using the engine ID of the authoritative agent. For informs, the authoritative SNMP agent
is the remote agent. You therefore need to configure the remote agent’s SNMP engine ID before you can send proxy
requests or informs to it.
Example
Console(config)#snmp-server user steve group r&d v3 auth md5 greenpeace
priv des56 einstien
Console(config)#snmp-server user mark group r&d remote 192.168.1.19 v3
auth md5 greenpeace priv des56 einstien
Console(config)#
426
