User’s Manual of SGSD-1022 / SGSD-1022P
SGSW-2840 / SGSW-2840P
The default is for Ethernet II packets.
[no]{permit | deny} eth2
{any | host source | source address-bitmask}
{any | host destination | destination address-bitmask}
[cos cos-value] [vid vid vid-bitmask] [ethertype protocol]
[no]{permit | deny} 802.3
{any | host source | source address-bitmask}
{any | host destination | destination address-bitmask}
[cos cos-value] [vid vid vid-bitmask]
tagged-eth2 – Tagged Ethernet II packets.
untagged-eth2 – Untagged Ethernet II packets.
tagged-802.3 – Tagged Ethernet 802.3 packets.
untagged-802.3 – Untagged Ethernet 802.3 packets.
any – Any MAC source or destination address.
host – A specific MAC address.
source – Source MAC address.
destination – Destination MAC address range with bitmask.
address-bitmask22 – Bitmask for MAC address (in hexidecimal format).
cos-value - Class-of-Service value (Range: 0-7)
vid – VLAN ID. (Range: 1-4094)
vid-bitmask22 – VLAN bitmask. (Range: 1-4095)
protocol – A specific Ethernet protocol number. (Range: 0-ffff hex.)
protocol-bitmask22 – Protocol bitmask. (Range: 600-fff hex.)
Default Setting
None
Command Mode
MAC ACL
22. For all bitmasks, “1” means care and “0” means ignore.
Command Usage
New rules are added to the end of the list.
The ethertype option can only be used to filter Ethernet II formatted packets.
A detailed listing of Ethernet protocol types can be found in RFC 1060. A few of the more common types include the
following: -0800 -IP -0806 -ARP -8137 -IPX To define more than one protocol, set the equivalent binary bit to “1” to
indicate the required protocols.
Example
This rule permits packets from any source MAC address to the destination address 00-e0-29-94-34-de where the
511
