GigaStudio 4 Reference Manual 93
0 – Internal: The LFO depth is controlled solely by the Internal Depth control.
1 – Mod Wheel: An external mod wheel controller determines the LFO depth, with its maximum limit set by
the External Depth control.
2 – Breath Control:
An external breath controller determines the LFO depth, with its maximum limit set by
the External Depth control.
3 – Int+Mod Wheel:
This allows for a constant amount of LFO depth supplied by the Internal LFO function,
with additional modulation provided by an external mod wheel. These work as described above under 0 -
Internal and 1 - Mod Wheel.
4 – Int+Breath Ctrl:
This allows for a constant amount of LFO depth supplied by the Internal LFO function,
with additional modulation provided by an external breath controller. These work as described above under 0
- Internal and 2 – Breath Control.
Internal Depth (-4800 to 4800)
This determines the amount of LFO modulation when Internal is the control source (described above).
Negative values and positive values give the same audible effect, but with multiple layers or instruments, you
might want to have one sound increasing in level while another sound decreases in level, in a complementary
way.
External Depth (-4800 to 4800)
This determines the amount of LFO modulation when Mod Wheel or Breath Control is selected as a control
source, as described previously. Negative values and positive values work as described for Internal Depth.
Invert (on/off)
Turning this on is the equivalent to changing the Depth parameters from a positive value to the equivalent
negative value, or vice-versa.
Synch (on/off)
When on, all LFOs start from the same starting point. When off, all LFOs are free-running.
Pitch LFO Section
The Pitch LFO provides vibrato effects (periodic variations in pitch).
