No.
(Addr
Hex.)
Name LCD Display Description Values Page
b3-03
(0193)
Speed Search
Deceleration Time
SpdSrch Dec Time
Sets output frequency reduction time during Speed Search. Default: 2.0 s
Min.: 0.1
Max.: 10.0
–
b3-04
(0194)
V/f Gain during Speed
Search
SpdSrch V/f
Determines how much to lower the V/f ratio during Speed
Search.
Output voltage during Speed Search equals the V/f setting
multiplied by b3-04.
Note: Available control mode for parameter b3-04
varies by drive model:
Models 2A0004 to 2A0415, 4A0002 to 4A0675,
and 5A0003 to 5A0242:
Available when A1-02 = 0
Models 4A0930 and 4A1200: Available when
A1-02 = 0, 2
Default: <2>
Min.: 10%
Max.: 100%
–
b3-05
(0195)
Speed Search Delay
Time
Search Delay
When using an external contactor on the output side, b3-05
delays executing Speed Search after a momentary power loss to
allow time for the contactor to close.
Default: 0.2 s
Min.: 0.0
Max.: 100.0
–
b3-06
(0196)
Output Current 1 during
Speed Search
Srch Im Lvl1
Sets the current injected to the motor at the beginning of Speed
Estimation Speed Search. Set as a coefficient for the motor rated
current.
Default: <2>
Min.: 0.0
Max.: 2.0
–
b3-07
(0197)
Output Current 2 during
Speed Search (Speed
Estimation Type)
Srch Im Lvl2
Sets the amount of output current during Speed Estimation
Speed Search as a coefficient for the no-load current.
Note: This parameter is only available in models
4A0930 and 4A1200.
Default: <2>
Min.: 0.0
Max.: 5.0
–
b3-08
(0198)
Current Control Gain
during Speed Search
(Speed Estimation Type)
Srch ACR P Gain
Sets the proportional gain for the current controller during
Speed Search.
There is normally no need to change this parameter from the
default setting.
Default: <3>
Min.: 0.00
Max.: 6.00
–
b3-10
(019A)
Speed Search Detection
Compensation Gain
Srch Detect Comp
Sets the gain which is applied to the speed detected by Speed
Estimation Speed Search before the motor is reaccelerated.
Increase this setting if ov occurs when performing Speed Search
after a relatively long period of baseblock.
Default: 1.05
Min.: 1.00
Max.: 1.20
–
b3-12
(019C)
Minimum Current
Detection Level during
Speed Search
Srch I Deadband
Sets the minimum current detection level during Speed Search.
Note: This parameter is only available in models
4A0930 and 4A1200.
Default: 6.0
Min.: 2.0
Max.: 10.0
–
b3-14
(019E)
Bi-Directional Speed
Search Selection
Bidir Search Sel
0: Disabled
1: Enabled
0: Disabled (uses the direction of the frequency reference)
1: Enabled (drive detects which way the motor is rotating)
Default: <1>
Range: 0, 1
–
b3-17
(01F0)
Speed Search Restart
Current Level
SrchRestart Lvl
Sets the Speed Search restart current level as a percentage of the
drive rated current.
Default: 150%
Min.: 0
Max.: 200
–
b3-18
(01F1)
Speed Search Restart
Detection Time
SrchRestart Time
Sets the time to detect Speed Search restart. Default: 0.10 s
Min.: 0.00
Max.: 1.00
–
b3-19
(01F2)
Number of Speed Search
Restarts
Num of SrchRestr
Sets the number of times the drive can attempt to restart when
performing Speed Search.
Default: 3
Min.: 0
Max.: 10
–
b3-24
(01C0)
Speed Search Method
Selection
SpdSrch Method
0: CurrentDetection
1: Speed Estimation
0: Current Detection
1: Speed Estimation
Default: 0
Range: 0, 1
–
b3-25
(01C8) Speed Search Wait Time SpdSrch WaitTime
Sets the time the drive must wait between each Speed Search
restart attempt.
Default: 0.5 s
Min.: 0.0
Max.: 30.0
–
b3-26
(01C7)
Direction Determining
Level
Spd Search Meth
Sets the level that determines the direction of motor rotation.
Note: This parameter is only available in models
4A0930 and 4A1200.
Default: <2>
Min.: 40
Max.: 60000
–
b3-27
(01C9)
Start Speed Search
Select
SPD Search By AI
0: start from 0
1: start SPD
Selects a condition to activate Speed Search Selection at Start
(b3-01) or External Speed Search Command 1 or 2 from the
multi-function input.
0: Triggered when a Run command is issued (normal).
1: Triggered when an external baseblock is released.
Default: 0
Range: 0, 1
–
B.2 b: Application
YASKAWA ELECTRIC TOEP C710616 41E YASKAWA AC Drive - A1000 Quick Start Guide 269
B
Parameter List
