u Flange Type Models 2A0360 and 2A0415, 4o0250 to 4o0362, and 5A0192 and 5A0242
n Flange Type Exterior and Mounting Dimensions
LIFTING AND EYEBOLT DETAILS (3) EXTERNAL
COOLING FANS
(13)-MOUNTING HOLES
FOR 3/8 in. [M10] SCREWS
FRONT VIEW
AIR
AIR
Unit: in. [mm]
NOTE: Maximum surrounding air temperature is 50 °C (122 °F)
NOTE: Spreader bar required to avoid damage during lifting.
M10 THREAD
(2) MOUNTING BRACKETS
USED DURING TRANSPORT ONLY
REMOVE BEFORE INSTALLING
VER
TICAL
MOUNTING DIM
VER
TICAL
MOUNTING DIM
VER
TICAL
MOUNTING DIM
HORIZONTAL MOUNTING DIM HORIZONTAL MOUNTING DIM HORIZONTAL MOUNTING DIM
Figure 2.49 Models 2A0360 and 2A0415, 4o0250 to 4o0362, and 5A0192 and 5A0242
2.2 Flange Type Enclosure (NEMA 12 Backside) Dimensions & Heat Loss
YASKAWA ELECTRIC TOEP C710616 41E YASKAWA AC Drive - A1000 Quick Start Guide 89
2
Mechanical Installation
