2.2 Flange Type Enclosure (NEMA 12 Backside) Dimensions & Heat
Loss
u Flange Type Models 2A0004 to 2A0012, 4A0002 to 4A0005, and 5A0003 and 5A0004
n Flange Type Exterior and Mounting Dimensions
0.08
[2.1]
3.83
[97.2]
2.36
[60.0]
0.44
[11]
10.12 [257.0] 11.81 [300.0]
5.46
[138.8]
0.76
[19.3]
VER
TICAL MTG DIM
VER
TICAL MTG DIM
5.46
[138.8]
10.24 [260.0]
3.54 [90.0]
1.44 [36.6]
0.44
[11]
1.46
[37]
6.26
[159]
5.28
[134]
5.51
[140.0]
1.45
[37]
7.64
194.0
1.34
[34]
0.8
[20.3]
4.72
[120.0]
FRONT VIEW
HORIZONTAL MTG DIM
HORIZONTAL MTG DIM
0.11
[3]
(6)-MOUNTING
HOLES FOR
#10[M5] SCREWS
0.08
[2]
5.79
[147]
NOTE: Maximum surrounding air temperature is 50 °C [122 °F]
0.2
[5]
Unit: in. [mm]
Figure 2.9 Models 2A0004 to 2A0012, 4A0002 to 4A0005, and 5A0003 and 5A0004
2.2 Flange Type Enclosure (NEMA 12 Backside) Dimensions & Heat Loss
YASKAWA ELECTRIC TOEP C710616 41E YASKAWA AC Drive - A1000 Quick Start Guide 41
