Vision Model After Teaching
1. Place the target near the center of the work area.
2. Click Run to take an image.
3. Adjust the model bounding box to fully enclose the model.
Make it close to the perimeter of the model, as shown in the previous figure.
4. Move the origin marker to the center of the model.
l Drag the origin marker to the center of the model with the mouse
or
l
Click Edit, to open the Edit window (shown in the following figure).
o Click Center to center the marker on the bounding box
or
o Click on the outline of the model, then click Center to center the
marker on the found part
AdeptSight Camera Calibration Wizard - Manual, Arm-Mount
AdeptSight User's Guide, Version 3.2.x, Updated: 8/23/2012
Page 163
