70

Danfoss

Danfoss

18 Danfoss

18�1 Danfoss

Easy Installation

Termination

Addressing

Interface

Yes

Connection plug

No

RS485

Overview

Integrated interface

Where to connect: 2 RJ45 sockets on the right on the side cover

Communication address does not have to be assigned

4-pin wiring

Installation steps

Switch off the inverters and Solar-Log™

Connect inverters to the Solar-Log™

Connect the inverters to each other

Connect inverters to the Solar-Log™

The wiring is done using a

ready-made RJ45 data cable (optional extra; not supplied)

or

self-made cable connection with RS485 data cable and terminal block connector.

Caution

The Master Mode has to be deactivated in the Pro series devices. See the manufacturer's
manual for more detailed instructions.

Procedure

1.

Unscrew the side cover as shown in the inverter's instructions.

2. If you are making the cable yourself, connect the wires as shown in the following diagram:

Solar-Log™ terminal strip connector

RJ45 inverter

Terminal

PIN

► 1

6

► 3

1

► 3

2

► 4

3

Caution

Risk of damage to the unit!
The Solar-Log™ also has an RJ45 socket, which must never be connected to the RJ45
socket on the inverter.

Only connect inverters via the RS485/422 Solar-Log™ interface(s).
