Kayak — User Manual 121
Effects Subpanel
MP (Media Player)
In MP Mode the Effects Subpanel serves for controlling external machines.
This can be any type of device, which can be controlled by one of the
machine control protocols, like video/audio tape machines, hard disk
recorders, etc.
To select the desired machine for control, either toggle through the avail-
able machines by repeatedly pressing the
MP button, or hold down the MP
button and select the desired machine number.
The display shows the machine number, status and the timecode.
In MP Mode each digit button in the keypad represent a tape motion com-
mand. The command is indicated by a character or a graphical symbol on
the numeric keypad.
Button Functions
The record command is accomplished by holding down the Store button
and pressing the digit button 6 > .
The Edit button allows you to enter a timecode for the GOTO Timecode
command. You can enter the timecode, using the Undo/. button as delimiter.
The timecode entry has to be confirmed be the Enter button.
Table 5. MP Button Functions
Button Description
7 << Rewind
8 # Stop, shows E-to-E image, depending on machine setup
9 >> Fast forward
4 < Reverse play
5 || Still
6 > Play
1 -
Single step back (when machine is in still) decrease variable speed (when
machine is in variable speed) decrease shuttle speed (when machine is in
shuttle mode)
2 V Variable speed
3 +
Single step forward (when machine is in still) increase variable speed
(when machine is in variable speed) increase shuttle speed (when machine
is in shuttle mode)
0 S Shuttle mode
