306 Kayak — User Manual
Section 5 — Kayak Menu Summaries
C4fx for Kayak HD™ System
This Kayak HD system has 4 DPM Channels per M/E and the Advanced
Effects Option:
C4fx: Bank 00
C4fx: Bank 01
C4fx: Bank 02
Table 21. Push on/of
00 QUAD-ON Brings all 4 channels in from corners
01 C12sl-LR Slides C1 off screen, slides C2 on screen
02 C12sl-RL Slides C1 off screen, slides C2 on screen
03 C12sl-TB Slides C1 off screen, slides C2 on screen
04 C12sl-BT Slides C1 off screen, slides C2 on screen
05 QUAD-OFF Removes all 4 channels to corners
05 C21sl-LR Slides C2 off screen, slides C1 on screen
07 C21sl-RL Slides C2 off screen, slides C1 on screen
08 C21sl-TB Slides C2 off screen, slides C1 on screen
09 C21sl-BT Slides C2 off screen, slides C1 on screen
Table 22. Reduced size effects (over shoulder position)
10 Wipe12sq Square wipe reveals 2 over 1
11 Wipe21sq Square wipe removes 2 from 1
12 Wipe21LR Wipes 1 from 1
13 Wipe12LR Wipes 2 over 2
14 pgt12 Page turn adds 2
15 pgt21 Page turn removes 2
15 pgr12 Page roll adds 2
17 pgr21 Page roll removes 2
18 Wipe12sq Square wipe reveals 2 over 1
19 Wipe21sq Square wipe removes 2 from 1
Table 23. Page Turns full size
20 K12pg-ON Double sided page turn 2sec.
21 C1pgt-ON
22 C2pgt-ON
23 C3pgt-ON
24 C4pgt-ON
25 C1pgt-OFF
25 C2pgt-OFF
27 C3pgt-OFF
28 C4pgt-OFF
29 K12pg-OFF
