308 Kayak — User Manual
Section 5 — Kayak Menu Summaries
C4fx: Bank 06
Notes
Use of GLOBAL Channel
Although GLOBAL channel is supported, certain aspects may behave in a
non-intuitive manner.
Most of the effects in these libraries do not use GLOBAL, but cubes and
push/pull effects do. You may find that when you first load the effects
library some effects are not running as intended. Before running any effects
go to the menu DPM – Misc - Reset to Defaults and reset ALL PARAMS.
If some effects still run incorrect, be confident that there will be a software
update shortly. It may be that another version of effects library will be
required at that time.
Format
All effects in this library are built for 4:3 aspect ratio.
Standard
The effects in this library are built in 625/50 standard. The effects durations
are stored internally in a format that allows the system to recalculate the
duration for 525/60 standard. Effectively that means that effects do not
need to be re-built for use in 525/60 standard.
Table 27. Tiles and modulation
60 C1twinH
61 C1twinV
62 C1quad
63 C12twin
64 C1mod
65 C1expld
65 C1slitsON
67 C1slitsOFF
68 C1twinH
69 C1twinV
