370 Kayak — User Manual
Section 6 — System Operation
Panel CPU Reset
The original Kayak-1/-2 control panels needed a power cycle in order to
reset the CPU. The new board set has provisions for resetting the CPU by
pressing three pushbuttons simultaneously.
To reset the panel CPU, press pushbuttons T1 (Home), T9 (Top Delegation),
and T12 (Bottom Delegation) simultaneously on the menu display module
(see
Figure 294 ).
Figure 294. Panel CPU Reset—Keys T1, T9, and T12
T1 T9
T12
