Kayak — User Manual 31
System Components
Kayak Video Processor Frames
Kayak HD 4 RU Frame
Figure 7. Kayak 4RU Frame, Front View with Door Removed
ON OFF
Top M/E Slot
M/E 0 (PP)
Bottom M/E Slot
(M/E 1)
Controller
(and 0.5 M/E)
2 USB
(unused) Air Filter Fan Assembly
Flash
Memory
Power
Switch
Reset
Button RS-232
Power Supply Unit 1 Redundant Power Supply Unit 2 (option)
8448_01_
r1
PS2
Keyboard
VGA
