Kayak — User Manual 27
Introduction
Ram Recorder
The HD RAM Recorder is a solid state video server with 6 input/output
channels. All stills and clips are stored within a common data pool and may
be accessed by all 6 output channels. The HD RAM Recorder supports
video standards: 525, 625, 720, and 1080i.
Note To use the RAM Recorder, a new 6910000xx Controller Board in the Main-
frame is required. The new 6910000xx Controller Board does not support
software later than 6.8.8.
Total HD RAM Recorder storage size is based on line rate units and the
installed memory size of 4GB or 8GB, as shown in the following table.
Supported Control Protocols
• VTRs (BVW-75)
• AMP (Advanced Media Protocol). For Profile PVS, XP, K2, M Series,
and Turbo DDRs. RS422 Serial supported
• Video servers (Louth VDCP, Odetics)
• Routers/Routing Control Systems (Trinix™, Venus™, Triton™, and
third party routers; Jupiter™ and Encore™ router control systems)
• Control Systems (Grass Valley Andromeda™ and third-party systems)
• Grass Valley Under Monitor Displays (Serial tally for UMD. Requires
Grass Valley Andromeda™ system or third-part tally box such as Tally
Display Corp. or Image Video.)
• Grass Valley external Remote AUX Panels (CP-300 Series)
• ESAM II for audio-follow-video applications
• Edit controllers (native and Grass Valley Model 100 and 200 or DD35)
Table 1. HD RAM Recorder Storage Sizes
4GB 8GB
Line Rate Units Frames Seconds Frames Seconds
525i59.9 4911 163 9822 326
625i50 4161 165 8336 332
1080i50/sf25 863 33 1726 68
1080i60/59.9/sf30/29.9 863 28 1726 57
1080sf24/23.9 863 35 1726 71
720p50 1941 38 3883 77
720p60/59.9 1941 32 3883 64
