230 Kayak — User Manual
Section 5 — Kayak Menu Summaries
Keyer Wipe
A Keyer Wipe mask source allows selection of a wipe pattern from the ded-
icated pattern generator for the keyer. Touch the
Patt. Sel/Adj button in the
menu to bring up the wipe pattern selections available ( Figure 150 ). Select
a pattern from the display. The selected pattern will appear in the Patt.
Sel/Adj data pad window. Select the other datapads in the wipe menu to
adjust pattern modifiers. These include pattern positioner, rotate, H and V
multiply, and aspect controls, similar to the wipe controls. Modifiers are
controlled by the soft knobs on the right of the screen.
Figure 150. Keyer Menu - Wipe Mask
Complex Wipe 1 and 2
A mask can be generated from a complex wipe source. There are two
complex wipe generators available,
Complex Wipe 1 and 2 . The pattern for the
complex wipe is chosen in the same manner as the keyer wipe mask. The
complex mask wipe can also be modified for position, rotation, H and V
multiplication and aspect. In addition, wipes can be mixed and modulated.
Keyer and complex wipe masks must share the wipe generators with other
functions with wipe capability in the switcher. This resource sharing must
be considered when delegating one of the wipe generators to a mask.
CAUTION All controls in the Wipe1 Generator or the Wipe2 Generator affect the selected
wipe pattern generator.
