Figure 22-4 URPF application situation
In the above figure, Router A sends requests to the server Router B by faking messages whose source
address are 2.2.2.1/8 .In response, Router B will send the messages to the real ”2.2.2.1/8”. Such illegal
messages attack both Router B and Router C. The application of URPF technology in the situation described
above can avoid the attacks based on the Source Address Spoofing.
22.4.2 URPF Configuration Task Sequence
1. Enable URPF
2. Display and debug URPF relevant information
1. Globally enable URPF
Command
Explanation
Global mode
urpf enable
no urpf enable
Globally enable and disable URPF.
2. Display and debug URPF relevant information
Command
Explanation
Admin and Config Mode
show urpf
Display which interfaces have been
enabled with URPF function.
22.4.3 URPF Typical Example
SW1
SW2
SW3
Globally enable URPF
E1/0/8
E1/0/8
10.1.1.10/24
vlan1
E1/0/2
Vlan3
E3/2
Vlan4
E1/0/3
