5.4 MP2000 Series Machine Controller Parameter Details
5.4.2 Motion Setting Parameter Details
5-38
( 25 ) Filter
There are two types of acceleration/deceleration filter: an exponential acceleration/deceleration filter and a moving
average filter.
For details on each acceleration/deceleration parameter, refer to 6.1.6 Acceleration/Deceleration Settings on page
6-11 and 6.1.7 Acceleration/Deceleration Filter Settings on page 6-13.
OW
3A
Filter Time Constant
Setting Range
Setting Unit
Default Value
0 to 65535
0.1 ms
0
Description
Set the acceleration/deceleration filter time constant.
Always make sure that pulse distribution has been completed (i.e., that monitoring parameter IW
0C, bit 0 is ON)
before changing the time constant.
First, select the filter type by using the parameter Filter Type Selection (OW
03, bits 8 to B), and then change the filter
time constant.
Once the filter type is set using the motion command, the setting is held until the power is turned OFF or the filter type is
changed.
OW
3B
Bias Speed for Index Acceleration/Deceleration Filter
Setting Range
Setting Unit
Default Value
0 to 32767
Depends on the
speed unit set in
Function Setting 1
(setting parameter
OW
03, bits 0
to 3)
0
Description
Set the bias speed for the exponential acceleration/deceleration filter.
The setting unit for this parameter depends on the Speed Unit Selection (OW
03, bits 0 to 3), but the
result of applying the speed unit setting is not shown here.
Position
Phase
Speed
Torque
Position
Phase
Speed
Torque
