10.4 Absolute Position Detection for Infinite Length Axes
10.4.2 Parameters Setting for Simple Absolute Infinite Length Position Control
10-17
10
Absolute Position Detection
( 3 ) SERVOPACK Parameters for Absolute Position Detection
SERVOPACK
Model
Parameter
Name
Setting Range
Units
Reference
Caution
Σ-III
Series
(SGDS),
Σ-V
Series
(SGDV)
Pn000.0
Direction Selection
0: Sets counterclockwise (CCW)
rotation as forward direction.
1: Sets clockwise (CW) rotation as
forward direction (reverse rotation
mode).
–
–
–
Pn205
Multiturn Limit Setting
0 to 65535
Rev
10.4.3 ( 3 )
Pn212
PG Dividing Pulse
16 to 1073741824
P/Rev
10.4.3 ( 3 )
Pn002.2
Absolute Encoder Usage
0: Uses absolute encoder as an abso-
lute encoder.
1: Uses absolute encoder as an incre-
mental encoder.
–
10.4.3 ( 1 )
Σ-II
Series
(SGDM, SGDH)
Pn000.0
Direction Selection
0: Sets counterclockwise (CCW)
rotation as forward direction.
1: Sets clockwise (CW) rotation as
forward direction (reverse rotation
mode).
–
–
–
Pn205
Multiturn Limit Setting
0 to 65535
Rev
10.4.3 ( 3 )
Pn201
PG Divider
16 to 16384
P/Rev
10.4.3 ( 2 )
Pn002.2
Absolute Encoder Usage
0: Uses absolute encoder as an abso-
lute encoder.
1: Uses absolute encoder as an incre-
mental encoder.
–
10.4.3 ( 1 )
Σ-I
Series
(SGDA, SGDB)
Cn-0001,
Bit E
Encoder Selection
0: Incremental encoder
1: Absolute encoder
–
10.4.3 ( 1 )
Cn-0002,
Bit 0
Rotation Direction Selec-
tion
0: Sets counterclockwise (CCW)
rotation as forward rotation.
1: Sets clockwise (CW) rotation as
forward rotation (reverse rotation
mode).
–
–
–
