12.2 Troubleshooting System Errors
12.2.4 System Register Configuration and Error Status
12-14
[ c ] Ladder Program User Operation Error Codes 1
* Yes: Can be set to value other than system default from the user program.
No: The system default cannot be changed from the user program.
[ d ] Ladder Program User Operation Error Codes 2
* No: The system default cannot be changed from the user program.
Error
Code
Error Contents User* System Default Value
Integer Op-
erations
0001H Integer operation - underflow Yes −32768 [−32768]
0002H Integer operation - overflow Yes 32767 [32767]
0003H Integer operation - division error Yes The A register remains the same.
0009H Double-length integer operation - underflow Yes −2147483648 [−2147483648]
000AH Double-length integer operation - overflow Yes 2147483647 [2147483647]
000BH Double-length integer operation - division error Yes The A register remains the same.
010 H
Operation error drawing - integer operation
error ( = 1 to B)
No Default indicated above.
Real
Number
Operation
0010H Integer storage - non-numeric error Yes Store not executed. [00000]
0011H Integer storage - underflow Yes Store not executed. [ −32768]
0012H Integer storage - overflow Yes Store not executed. [+32767]
0021H Real number storage - underflow Yes Store not executed. [ −1.0E+38]
0022H Real number storage - overflow Yes Store not executed. [1.0E+38]
0023H Real number operation - division-by-zero error Yes
Operation not executed.
The F register remains the same.
0030H
Real number operation - invalid operation
(non-numeric)
No Operation not executed.
0031H Real number operation - exponent underflow No 0.0
0032H Real number operation - exponent overflow No Maximum value
0033H
Real number operation - division error (non-
numeric 0/0)
No Operation not executed.
0034H Real number storage - exponent underflow No Stores 0.0.
0035H Real number operation - stack error
0040H
to
0059H
Standard System Functions
Real number operation errors
No
Interrupt operation and output =
0.0
0040H: SQRT 0041H: SIN 0042H: COS 0043H: TAN
0044H: ASIN 0045H: ACOS 0046H: ATAN 0047H: EXP
0048H: LN 0049H: LOG 004AH: DZA 004BH: DZB
004CH: LIM 004DH: PI 004EH: PD 004FH: PID
0050H: LAG 0051H: LLAG 0052H: FGN 0053H: IFGN
0054H: LAU 0055H: SLAU 0056H: REM 0057H: RCHK
0058H: BSRCH 0059H: SQRT
1000H or 2000H is added for an index error.
Error Code Error Contents User* System Default
Integer - Real
Number
Operations
1000H Index error within drawing No
Execute again with i, j = 0.
The i and j register remains the same.
2000H Index error within function No
Execute again with i, j = 0.
The i and j register remains the same.
Integer
Operation
060H
to
077H
( = 1,2)
Integer system functions
Index error
No
Operation stopped and output = input.
The A register remains the same.
06DH: PI 06DH: PD 06FH: PID 070H: LAG
071H: LLAG 072H: FGN 073H: IFGN 074H: LAU
075H: SLAU 076H: FGN 077H: IFGN
