7.2 Motion Command Details

7.2.3 Zero Point Return (ZRET)

7-27

7

Motion Commands

Related Parameters

Parameter

Name

Setting

Fixed Parameter

No. 1, Bit 5

Deceleration LS
Inversion Selection

Set whether or not to inverse the polarity of DI_5 signal used as DEC2 sig-
nal.
0: Do not invert
1: Invert
However, the deceleration limit signal for zero point return (OW

05, bit

8) will not be invert even if this bit is set to 1 (invert).

Fixed Parameter

No. 21, Bit 0

Deceleration LS Signal
Selection

Select the signal to be used as DEC2.
0: Setting parameter OW

05, bit 8

1: DI_5

OW

03,

Bits 0 to 3

Speed Unit Selection

Select the setting unit for OL

10 (Speed Reference Setting), OL

3E

(Approach Speed), and OL

40 (Creep Rate.)

0: Reference unit/s
1: 10

n

reference units/min

2: Percentage of rated speed (1 = 0.01%)
3: Percentage of rated speed (1 = 0.0001%)

OW

05, Bit 8

Zero Point Return
Deceleration LS Signal
(DEC2)

Used to input DEC2 signal from the ladder program when the bit 0 of fixed
parameter No.21 is 0.
0: OFF
1: ON

OL

10

Speed Reference
Setting

Set the speed to use when starting a zero point return.
Only a positive value can be set; a negative value will result in an error.

OW

18

Override

This parameter allows the Zero Point Return speed to be changed without
changing the Speed Reference Setting (OL

10). Set the speed as a per-

centage of the Speed Reference Setting. This setting can be changed during
operation.
Setting range: 0 to 32767 (0% to 327.67%)
Setting unit: 1 = 0.01% (Example) Setting for 50%: 5000

OW

3C

Zero Point Return
Method

4: DEC2 + ZERO Signal Method

OL

3E

Approach Speed

Set the approach speed.
Only a positive value can be set; 0 or a negative value will result in an error.

OL

40

Creep Rate

Set the creep speed.
Only a positive value can be set; 0 or a negative value will result in an error.

OL

42

Zero Point Return Travel
Distance

Set the travel distance from the point where the ZERO signal is detected
after passing the DEC2 signal.
If the sign is positive, travel will be toward the zero point return direction; if
the sign is negative, travel will be away from the zero point return direction.
