7.3 Motion Subcommands
7.3.2 Read Fixed Parameters (FIXPRM_RD)
7-86
7.3.2 Read Fixed Parameters (FIXPRM_RD)
The FIXPRM_RD command reads the current value of the specified fixed parameter and stores the value in the moni-
toring parameter IL
56 (Fixed Parameter Monitor).
( 1 ) Executing/Operating Procedure
1.
Check to see if all the following conditions are satisfied.
2.
Set OW
0A to 5 to execute the FIXPRM_RD motion subcommand.
The FIXPRM_RD will read the specified fixed parameter’s current value and store the code in the monitoring
parameter.
IW
0A will be 5 during command execution.
IW
0B, bit 0 will turn ON during the command processing and will turn OFF when the command processing
has been completed.
3.
Set OW
0A to 0 to execute the NOP motion command and then complete the monitoring operation.
( 2 ) Related Parameters
[ a ] Setting Parameters
[ b ] Monitoring Parameters
No.
Execution Conditions
Confirmation Method
1
Motion subcommand execution has been completed.
IW
0A is 0 and IW
0B, bit 0 is OFF.
Parameter
Name
Setting
OW
0A
Motion Subcommand
The Read Fixed Parameter subcommand is executed when this parameter is set to
5.
OW
5C
Fixed Parameter Number
Set the parameter number of the fixed parameter to be read.
Parameter
Name
Monitor Contents
IW
0A
Motion Subcommand
Response Code
Indicates the motion subcommand that is being executed.
The response code is 5 during FIXPRM_RD command execution.
IW
0B
Bit 0
Command Execution
Flag
Turns ON during FIXPRM_RD command execution.
Turns OFF when execution has been completed.
IW
0B
Bit 3
Command Error
Completed Status
Turns ON if an error occurs during FIXPRM_RD command execution.
Turns OFF when another command is executed.
IW
0B
Bit 8
Command Execution
Completed
Turns ON when FIXPRM_RD command execution has been completed.
IL
56
Fixed Parameter
Monitor
Stores the data of the specified fixed parameter number.
