User’s Manual of WGS3-24000 / WGS3-24240
351
4.7.6.6 PIM-SM RP Set Summary
Figure 4-6-83 PIM-SM RP Set Summary
Non-Configurable Data
Object
Description
• Group Address
Displays IP multicast group address.
• Group Mask
Displays Multicast group address mask.
• Address
Displays IP address of the Candidate-RP.
• Hold Time
The holdtime of a Candidate-RP.If the local router is not the BSR, this value is 0.
• Expiry Time
Component
The minimum time remaining before the Candidate-RP will be declared.
• Refresh button
Refresh the data on the screen with the present state of the data in the router.
4.7.6.7 PIM-SM Candidate RP Summary
Figure 4-6-84 PIM-SM Candidate RP Summary
