User’s Manual of WGS3-24000 / WGS3-24240
86
4.2.8.4 Port Summary
Figure 4-2-39 Port Summary Statistics
Selection Criteria
Object
Description
• Slot.Port
Selects the interface for which data is to be displayed or configured.
Non-Configurable Data
Object
Description
• ifIndex
This object indicates the ifIndex of the interface table entry associated with this
port on an adapter.
• Total Packets Received
Without Errors
The total number of packets received that were without errors.
• Packets Received With
Error
The number of inbound packets that contained errors preventing them from being
deliverable to a higher-layer protocol.
• Broadcast Packets
Received
The total number of good packets received that were directed to the broadcast
address. Note that this does not include multicast packets.
• Packets Transmitted
Without Errors
The number of frames that have been transmitted by this port to its segment.
• Transmit Packet Errors The number of outbound packets that could not be transmitted because of errors.
• Collision Frames
The best estimate of the total number of collisions on this Ethernet segment.
• Time Since Counters
The elapsed time, in days, hours, minutes, and seconds since the statistics for
