Enable 802.1x wired authentication
Article • 03/16/2023 • Applies to: Surface Hub, Surface Hub 2S
The November 14, 2017 update to Windows 10 (build 15063.726) enabled 802.1x
wired authentication policy configuration on Surface Hub devices. The feature allows
organizations to enforce standardized wired network authentication using the
IEEE
802.1x authentication protocol . This was already available for wireless authentication
using WLAN profiles via MDM or provisioning package. This topic explains how to
configure a Surface Hub for use with wired authentication.
Enforcement and enablement of 802.1x wired authentication on Surface Hub can be
done through MDM
OMA-URI profiles or provisioning package.
The primary configuration to set is the LanProfile policy. Depending on the
authentication method selected, other policies may be required, either the EapUserData
policy or through MDM policies for adding user or machine certificates (such as
ClientCertificateInstall for user/device certificates or RootCATrustedCertificates for device
certificates).
To configure Surface Hub to use one of the supported 802.1x authentication methods,
utilize the following OMA-URI.
This OMA-URI node takes a text string of XML as a parameter. The XML provided as a
parameter should conform to the
Wired LAN Profile Schema including elements from
the 802.1X schema .
In most instances, an administrator or user can export the LanProfile XML from an
existing PC that is already configured on the network for 802.1X using this following
NETSH command.
LanProfile policy element
./Vendor/MSFT/SurfaceHub/Dot3/LanProfile
netsh lan export profile folder=.
