Customize wall mount of Surface Hub
2S 50"
Article • 01/03/2023
This article provides guidance for physically installing the Microsoft Surface Hub 2S 50."
For information about installing the 85" see
Install and mount Surface Hub 2S 85" .
If not using certified mounting solutions, you can mount Surface Hub 2S 50" using
readily available retail hardware.
Surface Hub 2S 50" recommended mounting measurements:
Item Description Notes
Height from bottom of Surface Hub 2S 50" 1026.5 mm (40.41”) Recommended
Height from top of Surface Hub 2S 50" 1767.2 mm (69.57”) Recommended
Height from center of mount 1397 mm (55”) Recommended
1. Measure 1026.5 mm (40.41”) from the floor level to set the recommended
minimum height.
2. Measure 1767.2 mm (69.57”) from the floor level to set the recommended top
height.
Set wall mount measurements
