Connector and location
Label
Description
USB type B, bottom I/O
Provides USB connection for video ingest touchback.
Connector and location
Label
Description
USB type A, side I/O
Provides 1 USB 3.0 connection for USB devices.
Wake-on USB capable.
USB type A, bottom I/O with blue
insulator
Provides USB 3.0 connection.
3.5mm, bottom I/O
Provides analog audio out.
Display port, bottom I/O
Provides mirrored video out function to another
display.
IEC/EN60320-C13 receptacle with
hard switch
Provides AC input and compliance with EU power
requirements.
RJ45, bottom I/O
Connects to Ethernet.
RJ11, bottom I/O
Connects to room control systems.
Additional connections
7
Note
Surface Hub can be used continuously for a maximum of 18 hours a day. To
optimize for efficiency, Surface Hub uses smart sensors to turn off the LED screen
when presence is no longer detected, which means there is no need to power it
down at the end of the day. If the unit is installed in a 24-hour workplace
environment, the sensors can be disabled to comply with the 18 hour per day
maximum use recommendation. Note that prolonged display of a video signal may
cause burned-in or image retention to occur on the screen. To learn more about
managing power settings, see:
