Biomedical Test System
ESU Module
14
14-5
Running ESU Autosequence Tests
To begin running ESU autosequence tests, connect your medTester 5000C to
your 454A ESU Analyzer. These two instruments are connected through the
COM2 port on the medTester and the RS-232 serial port on the ESU
analyzer. In addition, all ESU analyzers can alternately connect through the
Wedge Port Expander.
Note
The medTester must be set to 2400 baud to communicate with
the RF303
RS
. You can set the BAUD rate through the
UTIL /
RS232 PORT
menu path.
Note
Refer to Chapter 1, General Information - Accessories, or the current
Fluke Biomedical Price List for the correct serial cable part
number needed.
From the medTester 5000C ESU menu, select the autosequence name for the
autosequence you wish to run. The name and number of the selected
autosequence appears on the display:
If a safety autosequence has executed since power up of the medTester, you
can have the medTester use the previously input prompt information for the
current ESU autosequence, from this prompt:
Press F5 for all device info prompts
USE PREVIOUS STARTING INFORMATION?
YES
F1
NO
F2
