Three-Phase 600 V Class Drive Models 5A0041 to 5A0099
Table A.2 Power Ratings Continued (Three-Phase 600 V Class)
Item
Specification
Drive Models
5A0041
5A0052
5A0062
5A0077
5A0099
Maximum Applicable Motor Capacity (HP)
<1>
40
50
60
75
100
Input
Input Current (A)
<2>
44
54
66
80
108
Rated Voltage
Rated Frequency
Three-phase 500 to 600 Vac 50/60 Hz
Allowable Voltage Fluctuation
-10 (-15) to +10%
Allowable Frequency Fluctuation
±5%
Input Power (kVA)
50
62
75
91
123
Output
Rated Output Capacity (kVA)
<3>
<4>
41
52
62
77
99
Rated Output Current (A)
<4>
41
52
62
77
99
Overload Tolerance
110% of rated output for 60 s
140% of rated output for 0.5 s
Carrier Frequency
User adjustable between 1 and 12.5 kHz
Maximum Output Voltage (V)
Three-phase 500 to 600 Vac (proportional to input voltage)
Maximum Output Frequency (Hz)
240 Hz
<1> The motor capacity (HP) refers to a NEC rated 4-pole motor. The rated output current of the drive output amps should be equal to or greater than
the motor current. Select the appropriate capacity drive if operating the motor continuously above motor nameplate current.
<2> Assumes operation at the rated output current. Input current rating varies depending on the power supply transformer, input reactor, wiring
connections, and power supply impedance.
<3> Rated motor capacity is calculated with a rated output voltage of 575 V.
<4> Carrier frequency can be increased to 2 kHz while keeping this current derating. Higher carrier frequency settings require derating.
A.1 Power Ratings
