B.2 b: Application

Application parameters configure the source of the Run command, DC Injection Braking, Speed Search, timer functions, PI

control, Energy Savings, and a variety of other application-related settings.

u

b1: Operation Mode Selection

No.

(Addr.

Hex)

Name

LCD Display

Description

Values

Page

b1-01

(180)

Frequency Reference

Selection for AUTO

mode

Ref Source 1

0: Operator

1: Analog Input

2: Serial Com

3: Option PCB

0: HOA keypad

1: Terminals (Analog Input Terminals)

2: Serial communications (APOGEE FLN, BACnet,

MEMOBUS/Modbus, or Metasys N2)

3: Option card

Default: 1

Range: 0 to 3

121

b1-02

(181)

Run Command

Selection for AUTO

mode

Run Source 1

1: Digital Inputs

2: Communication

3: Option PCB

1: Control Circuit Terminal

2: Serial communications (APOGEE FLN, BACnet,

MEMOBUS/Modbus, or Metasys N2)

3: Option card

Default: 1

Range: 1 to 3

123

b1-03

(182)

Stopping Method

Selection

Stopping Method

0: Ramp to Stop

1: Coast to Stop

2: DCInj to Stop

3: Coast w/Timer

0: Ramp to stop

1: Coast to stop

2: DC Injection Braking to stop

3: Coast with timer

Default: 1

Range: 0 to 3

123

b1-04

(183)

Reverse Operation

Selection

Reverse Oper

0: Reverse Enabled

1: Reverse Disabled

0: Reverse enabled

1: Reverse disabled

Default: 1

Range: 0, 1

151

b1-08

(187)

Run Command

Selection in

Programming Mode

RUN dur PRG Mode

0: Run

Disabled@PRG

1: ModeRun

Enabled@PRG

2: Prg only @ Stop

0: Run command is not accepted while in Programming Mode

1: Run command is accepted while in Programming

2: Prohibit entering Programming Mode during Run

Default: 0

Range: 0 to 2

b1-11

(1DF)

Drive Delay Time

Setting

Run Delay Time

After a Run command is entered, the drive output waits until

this delay time has passed before starting.

Default: 0 s

Min.: 0

Max.: 600

b1-14

(1C3)

Phase Order Selection

Rotation Sel

0: Standard

1: SwitchPhaseOrder

0: Standard

1: Switch phase order (reverses the direction of the motor)

Default: 0

Range: 0, 1

151

b1-17

(1C6)

Run Command at Power

Up

Run Cmd @ Pwr On

0: Cycle Ext Run

1: Accept Ext Run

0: Disregarded.

A new Run command must be issued after power up.

1: Allowed.

Motor will start immediately after power up if a Run command

is already enabled.

Default: 1

Range: 0, 1

151

u

b2: DC Injection Braking and Short Circuit Braking

No.

(Addr.

Hex)

Name

LCD Display

Description

Values

Page

b2-01

(189)

DC Injection Braking

Start Frequency

DCInj Start Freq

Sets the frequency at which DC Injection Braking starts when

“Ramp to stop” (b1-03 = 0) is selected.

Default:

<1>

Min.: 0.0 Hz

Max.: 10.0 Hz

151

b2-02

(18A)

DC Injection Braking

Current

DCInj Current

Sets the DC Injection Braking current as a percentage of the

drive rated current.

Default: 50%

Min.: 0

Max.: 100

152

b2-03

(18B)

DC Injection Braking

Time at Start

DCInj Time@Start

Sets DC Injection Braking time at start. Disabled when set to

0.00 seconds.

Default: 0.00 s

Min.: 0.00

Max.: 10.00

152

b2-04

(18C)

DC Injection Braking

Time at Stop

DCInj Time@Stop

Sets DC Injection Braking time at stop.

Default: 0.00 s

Min.: 0.00

Max.: 10.00

152

b2-09

(1E1)

Motor Pre-Heat Current

2

Preheat Current

Determines the percentage of motor rated output current used

for the motor pre-heat function.

Default: 5%

Min.: 0

Max.: 100

B.2 b: Application

264
