CHAPTER COLOR
COLOR 273
9
Using Hue and Sat Curves With the DaVinci Resolve Control
Surface
Using these curves with the DaVinci Resolve control surface unlocks their speed, letting you make fast,
controlled adjustments to specific elements within each scene.
To open the Hue and Sat curve controls on the DaVinci Resolve control surface:
• Press the CURVES display button on the center panel.
To exit the Hue and Sat curve controls:
• Press the MAIN display button on the center panel.
To adjust the principle color regions using knobs:
• Adjust one of the 18 rotary knobs in the PRIMARIES CURVE GRADE control groups
corresponding to the RED/YELLOW/GREEN/CYAN/BLUE/MAGENTA colors paired
with HUE/SAT/LUM.
To sample a region of a shot to place curve control points:
1. Press the display button corresponding to the curve you want to adjust (HUE - HUE,
HUE - SAT, HUE - LUM, LUM - SAT).
2. Press the CURSOR button located above the fourth trackball.
3. Use the fourth trackball to move the onscreen cursor to the pixel you want to sample.
4. Press the first of the three buttons underneath the fourth trackball to sample the color
at the position of the cursor.
Three control points appear on the currently selected curve. The outer two control
points define region of the curve you’re adjusting. The center control point lets you
make the actual adjustment and selected by default.
5. To hide the cursor when you’re finished sampling, press the CURSOR button again.
Methods of selecting and adjusting individual control points using the master trackball of the
center panel:
To select a control point to adjust:
Spin the fourth ring control to the right or left to select the next
control point in that direction. It takes about half of a turn to
select another control point.
To move a selected control point:
Adjust the fourth trackball to move the control point up, down,
left, or right. Selected control points are constrained between
whichever control points are to the left and right.
