Blackmagic Design DaVinci Resolve Advanced Panel User Manual
Page 299
CHAPTER
VIEWER
VIEWER
299
10
Waveform displays
DaVinci Resolve offers a number of built-in waveform displays, all of which work at the native resolution
of the system rather than at the video standard selected for clip playout. This means you can see the
full data range of the source image with the correction applied, regardless of which video standard in
which you master.
The display option are: Waveform, Parade, Vectorscope, and Histogram. They allow you to monitor
the levels of the correction that are being applied to the image, and within each display there are the
controls to vary the brightness of the scale and information displayed.
Show Timecode at 30 fps
The final item on the list of options is a checkbox to show the timecode in the timecode display at 30 fps.
This is used to show timecode as it would appear on tape in a 2:3 pull up mode from a 24 fps project.
