CHAPTER CONFIGURATION
CONFIGURATION 59
6
The Deck Capture and Playback controls are as follows:
Video capture & playback: Selects video standard from the pulldown list.
There is also a checkbox selection to enable stereo video ingest
and playout.
Video connection: Selects between the available connections: YUV 422 SDI, RGB
444 Dual Link and 444 single link using 3 Gb/s. Note these options
depend on which video capture card you are using and are all
available with the Blackmagic Design DeckLink HD Extreme 3
and 3D.
Colorspace Conversion: DaVinci Resolve normally uses computer RGB levels internally and so
the normally scaled legal video option will perform a color mapping
conversion to and from the SMPTE video levels when ingesting from
or recording to tape. By selecting the Unscaled full range data no
scaling will be performed in either ingest or playout.
Video Bit Depth: 10 bit is the current option.
Edit mode for recording: Select whether to record the material to tape in Insert, Assemble, or
Crash record edit mode.
Auto Edit: If your deck supports it, this is the best method to record video to
the deck. If deselected, a basic the Edit On/Off mode can be used.
Non Auto Edit timing: Adjusts the edit synchronization for the deck when auto edit is
not selected.
Deck Preroll: Set the number of seconds for preroll depending on the
performance of your deck.
Add and remove 3:2 pulldown: Enable for working with NTSC/59.94i-based material. This will remove
the 3:2 sequence on ingest or will add 3:2 on export to tape.
Video output sync source: With the Decklink this is set to Auto, but with some other capture
cards you may wish to set the sync source to ‘Reference’ for playout
and ‘Input’ for ingest.
